--- title: Melco connection troubleshooting description: In the event your Melco machine stops communicating with the PC we need to follow the steps below. --- [Skip to content](https://help.amayauk.com/melco-connection-troubleshooting#main-content) [Submit a ticket](https://help.amayauk.com/kb-tickets/new?hsLang=en) [![Amaya New Logo White](https://help.amayauk.com/hs-fs/hubfs/Amaya%20New%20Logo%20White.png?width=270&height=120&name=Amaya%20New%20Logo%20White.png)](https://www.amayauk.com/) Open main navigation Close main navigation - [Submit a ticket](https://help.amayauk.com/kb-tickets/new) How can we help you? - There are no suggestions because the search field is empty. 1. [Help Centre](https://help.amayauk.com/?hsLang=en) 2. [Melco](https://help.amayauk.com/melco?hsLang=en) 3. [Troubleshooting](https://help.amayauk.com/melco?hsLang=en#troubleshooting) # Melco connection troubleshooting Use this checklist if your Melco machine stops communicating with the PC. - **Check the network connections.** - Check all cables (swap with a known working machine if possible). - If connected via a switch or hub, plug the embroidery machine directly into the computer. - Check whether Windows has recently updated. - Temporarily turn off any antivirus and firewall software that could be blocking the connection. - **Confirm the network connection in Melco OS.** - Go to *Tools \> Options*. ![](https://help.amayauk.com/hs-fs/hubfs/image-png-Oct-02-2025-10-18-47-4332-AM.png?width=396&height=175&name=image-png-Oct-02-2025-10-18-47-4332-AM.png) - Open the *Ethernet* tab. Select the LAN card connected to the machines (it should be highlighted in blue), then click *Apply* and *OK*. - Reboot Melco OS and the machine to reconnect. - **Use the advanced connection menu (enable via registry if required).** **Warning:** Only make the change described below. Editing other registry keys can cause Windows system errors. - - In the Windows search bar, type *RegEdit* and open the Registry Editor. - Navigate to: `HKEY_CURRENT_USER\Software\Melco\MC\Settings` - Double-click `EnetAdvanced` and change the value from `0` to `1`, then close the Registry Editor. The advanced Ethernet menu will now be available in Melco OS. ![](https://help.amayauk.com/hs-fs/hubfs/image-png-Oct-02-2025-10-27-08-0122-AM.png?width=670&height=451&name=image-png-Oct-02-2025-10-27-08-0122-AM.png) - If no machines appear, the machine may require a Manual USB Reflash, follow the steps on the link below to complete this: - [Manual USB Reflash](https://help.amayauk.com/emt16x-how-to-flash-the-new-main-pcb-manually?hsLang=en) - If you see the machine in the left box with a `+` next to it, it needs to be *Unpaired* and *Reclaimed*. Select the machine on the left and click *Unpair*. ![](https://help.amayauk.com/hs-fs/hubfs/image-png-Oct-02-2025-10-27-22-8393-AM.png?width=555&height=856&name=image-png-Oct-02-2025-10-27-22-8393-AM.png) - Close the network settings window, then reopen it. The machine should now appear without a `+`. Select the machine and click the `>>>>>` button. The machine should beep, appear in the right-hand box, and sync to the computer. - **Reinstall the software.** - If the above does not work, reinstall Melco OS. Follow the steps in the Melco OS Installation Guide (available on the support page). - **Try a different PC.** - Install the software on another PC and confirm the machine can connect from there. - **Still having issues?** The problem may be an electrical failure and a service visit could be required. [Request support.](https://help.amayauk.com/kb-tickets/new?hsLang=en) - [Epson](https://help.amayauk.com/epson?hsLang=en#main-content) - [F2200 Operation Guides](https://help.amayauk.com/epson?hsLang=en#f2200-operation-guides) - [F1000 Operation Guides](https://help.amayauk.com/epson?hsLang=en#f1000-operation-guides) - [F3000 Operation Guides](https://help.amayauk.com/epson?hsLang=en#f3000-operation-guides) - [G6000 Operation Guides](https://help.amayauk.com/epson?hsLang=en#g6000-operation-guides) - [Garment Creator 2](https://help.amayauk.com/epson?hsLang=en#garment-creator-2) - [Melco](https://help.amayauk.com/melco?hsLang=en#main-content) - [Troubleshooting](https://help.amayauk.com/melco?hsLang=en#troubleshooting) - [EMT16X Training Videos](https://help.amayauk.com/melco?hsLang=en#emt16x-training-videos) - [EMT16X](https://help.amayauk.com/melco?hsLang=en#emt16x) - [EMT16 Plus](https://help.amayauk.com/melco?hsLang=en#emt16-plus) - [Amaya XT](https://help.amayauk.com/melco?hsLang=en#amaya-xt) - [Design Shop](https://help.amayauk.com/melco?hsLang=en#design-shop) - [Amaya XTS](https://help.amayauk.com/melco?hsLang=en#amaya-xts) - [Amaya non-XT](https://help.amayauk.com/melco?hsLang=en#amaya-non-xt) - [FAQs](https://help.amayauk.com/melco?hsLang=en#faqs) - [Software downloads](https://help.amayauk.com/melco?hsLang=en#software-downloads) - [Summit](https://help.amayauk.com/melco?hsLang=en#summit) - [Roland DG](https://help.amayauk.com/roland-dg?hsLang=en#main-content) - [Print & cut](https://help.amayauk.com/roland-dg?hsLang=en#print-cut) - [UV printers](https://help.amayauk.com/roland-dg?hsLang=en#uv-printers) - [Roland TY-300 DTF Printer](https://help.amayauk.com/roland-dg?hsLang=en#roland-ty-300-dtf-printer) - [Roland BN2-20/20A & BN2-30/30A Print & Cut](https://help.amayauk.com/roland-dg?hsLang=en#roland-bn2-20-20a-bn2-30-30a-print-cut) - [Roland TrueVIS Printers](https://help.amayauk.com/roland-dg?hsLang=en#roland-truevis-printers) - [Roland BD-8 & BD-12 UV Printers](https://help.amayauk.com/roland-dg?hsLang=en#roland-bd-8-bd-12-uv-printers) - [Roland MO-180 & MO-240 UV Printers](https://help.amayauk.com/roland-dg?hsLang=en#roland-mo-180-mo-240-uv-printers) - [Roland BY-20 DTF Printer](https://help.amayauk.com/roland-dg?hsLang=en#roland-by-20-dtf-printer) - [Roland MG-300 & MG-640 UV, Print & Cut](https://help.amayauk.com/roland-dg?hsLang=en#roland-mg-300-mg-640-uv-print-cut) - [Sabur](https://help.amayauk.com/sabur?hsLang=en#main-content) - [Software](https://help.amayauk.com/sabur?hsLang=en#software) - [Application](https://help.amayauk.com/sabur?hsLang=en#application) - [Maintenance](https://help.amayauk.com/sabur?hsLang=en#maintenance) - [White Toner Printers](https://help.amayauk.com/white-toner-printers?hsLang=en#main-content) - [FAQ's](https://help.amayauk.com/white-toner-printers?hsLang=en#faqs) - [Pro8432WT](https://help.amayauk.com/white-toner-printers?hsLang=en#pro8432wt) - [ProRIP Essentials](https://help.amayauk.com/white-toner-printers?hsLang=en#prorip-essentials) - [Forever](https://help.amayauk.com/forever?hsLang=en#main-content) - [Video tutorials](https://help.amayauk.com/forever?hsLang=en#video-tutorials) - [Laser Dark (No Cut)](https://help.amayauk.com/forever?hsLang=en#laser-dark-no-cut) - [Flex Soft (No Cut)](https://help.amayauk.com/forever?hsLang=en#flex-soft-no-cut) - [Laser Light (No Cut)](https://help.amayauk.com/forever?hsLang=en#laser-light-no-cut) - [Laser Transparent](https://help.amayauk.com/forever?hsLang=en#laser-transparent) - [Classic & Universal](https://help.amayauk.com/forever?hsLang=en#classic-universal) - [Laser Dark Cuttable](https://help.amayauk.com/forever?hsLang=en#laser-dark-cuttable) - [Multi Trans](https://help.amayauk.com/forever?hsLang=en#multi-trans) - [Waterslide](https://help.amayauk.com/forever?hsLang=en#waterslide) - [Hot Stamping Foils](https://help.amayauk.com/forever?hsLang=en#hot-stamping-foils) - [Subli-Light (No Cut)](https://help.amayauk.com/forever?hsLang=en#subli-light-no-cut) - [Laser Tattoo Paper](https://help.amayauk.com/forever?hsLang=en#laser-tattoo-paper) - [Subli-Flex (No Cut)](https://help.amayauk.com/forever?hsLang=en#subli-flex-no-cut) - [Subli-Dark (No Cut)](https://help.amayauk.com/forever?hsLang=en#subli-dark-no-cut) - [Five Star Universal](https://help.amayauk.com/forever?hsLang=en#five-star-universal) - [FAQs](https://help.amayauk.com/forever?hsLang=en#faqs) - [TransferRIP](https://help.amayauk.com/forever?hsLang=en#transferrip) - [SEF](https://help.amayauk.com/sef?hsLang=en#main-content) - [FAQ's](https://help.amayauk.com/sef?hsLang=en#faqs) - [Troubleshooting](https://help.amayauk.com/sef?hsLang=en#troubleshooting) - [Video tutorials](https://help.amayauk.com/sef?hsLang=en#video-tutorials) - [PolyPrint](https://help.amayauk.com/polyprint?hsLang=en#main-content) - [TexJet echo2](https://help.amayauk.com/polyprint?hsLang=en#texjet-echo2) - [TexJet shortee2](https://help.amayauk.com/polyprint?hsLang=en#texjet-shortee2) - [TexJet Plus](https://help.amayauk.com/polyprint?hsLang=en#texjet-plus) - [TexJet shortee](https://help.amayauk.com/polyprint?hsLang=en#texjet-shortee) - [TexJet echo](https://help.amayauk.com/polyprint?hsLang=en#texjet-echo) - [RIP software](https://help.amayauk.com/polyprint?hsLang=en#rip-software) - [DTF Xpress](https://help.amayauk.com/polyprint?hsLang=en#dtf-xpress) - [PreTreater Pro](https://help.amayauk.com/polyprint?hsLang=en#pretreater-pro) - [Troubleshooting](https://help.amayauk.com/polyprint?hsLang=en#troubleshooting) - [Stahls](https://help.amayauk.com/stahls?hsLang=en) - [DTF](https://help.amayauk.com/dtf?hsLang=en) [![Chill listening crop-3](https://help.amayauk.com/hs-fs/hubfs/Amaya%20Logo%20(Black).png?width=103&height=24&name=Amaya%20Logo%20(Black).png "Chill listening crop-3")](http://amayauk.com) Copyright © 2026, Amaya Sales UK Limited
